Batches of inputs

Reminder

Make sure you read the section on input files

As we discussed, you can define batches of inputs in file(s) whose paths are given by inputs.batches in your qaboard.yaml configuration.

qa/batches.yaml (default)

my-batch:
 inputs:
   - A.jpg
   - B.jpg

qa batch my-batch
#=> qa run --input A.jpg
#=> qa run --input B.jpg

qa batch --batch first-batch --batch second-batch

Setting a custom database

You can set a default database for all the batches in define in each file:

database: /some/path

my-batch:
  inputs: # will be relative to the database
  - Images/Demo3/A.jpg
  - Images/Demo2

Setting a custom database per batch

you-can-override-the-default-database:
  database:
    linux: /mnt/database
    windows: '\\\\storage\\database'
  inputs:
  - Images/Demo3/A.jpg
  - Images/Demo2

Specifying test configurations

Reminder

Make sure you read the section on configurations

Let's look at examples from one of Samsung's projects to illustrate how configurations can be given. In short, each image is processed by a tool named "CDE". We need to feed it config files and CLI arguments.

using-a-custom-configuration:
  configs:
  - base
  inputs:
  - Bayer/A.dng
  - Bayer/B.dng
# => configs == ["base"]
# => the code would load base/config.cde

multiple-configs:
  configs:
    - base
    - low-light
  inputs:
  - Bayer/A.dng
  - Bayer/B.dng
#=> configs == ["base", "low-light"]
#=> we merge 2 CDE configs

configs-can-be-complex-objects:
  configs:
    - base
    - low-light
    - cde:
      - "-w 9920"
      - "-h 2448"
      - "-it BAYER10"
  inputs:
  - Bayer/A.dng
  - Bayer/B.dng
# configs == ["base", "low-light", {"cde": ["-w 9920", "-h 2448", "-it BAYER10"]}]
# => Here we use the "cde" config parameter to pass CLI arguments to CDE.

each-input-can-have-its-own-configuration:
  configs:
    - base
  inputs:
  - Bayer/A.dng:
    #=> configs == ["base"]
  - Bayer/B.dng:
      - low-light
      - cde:
        - "-DD"
    #=> configs == ["base", "low-light", {"cde": ["-DD"]}]


each-input-can-have-its-own-configuration-and-appear-twice:
  configurations:
    - base
  inputs:
  - a.txt: {crop: A}
    #=> configurations == ["base", {"crop": ["A"]}]
  - a.txt: {crop: B}
    #=> configurations == ["base", {"crop": ["B"]}]
  - [a.txt, {crop: C}]
    #=> configurations == ["base", {"crop": ["C"]}]

Matrix batches

You can use "matrix" batches to run on combinations of configurations (and platfornms):

multiple-configs:
  inputs:
  - a.raw
  matrix:
    configs:
      -
          - base
          - tuning
      -
          - base

#=> `qa batch multiple-configs` will run
#   with [base, tuning] and [base]

Per-input extra configurations still work.

The syntax was inspired from DroneCI, GithubActions, AzurePipelines.

Interpolation

Matrix variables are interpolated using the ${matrix.variable} syntax:

my-batch-multiple-configs:
  inputs:
  - image.raw
  matrix:
    version: [1, 2]
  configs:
    - base-v${matrix.version}

# => will run with [base-v1] and [base-v2]

And elaborate complex testing strategies:

my-batch-multiple-values:
  inputs:
  - image.raw
  matrix:
    threshold: [1, 2, 3, 4]
    mode: ["a", "b"]
  configs:
    - base
    - block.threshold: ${matrix.threshold}
    - block.mode: ${matrix.mode}

# => will start 8 runs run with
#     [base, block.threshold: 1, block.mode: a
#     [base, block.threshold: 1, block.mode: b
#     [base, block.threshold: 2, block.mode: a
#     etc

Advanced users can use indexing: ${matrix.param[0]} or ${matrix.param[key]} according to the python formatting miniformat, if they use "complex" matrix parameters with objects/arrays/strings:

my-batch-matrix-object:
  inputs:
  - image.raw
  matrix:
    point: [
      {x: 10, y: 40},
      {x: 20, y: 50},
    ]
  configs:
    - base
    - flags: "-x=${matrix.point[x]} -y=${matrix.point[y]}"

Aliases for groups of batches

For convenience you can define aliases for batches you often run together. For instance you can do:

qa/batches.yaml

aliases:
  two-batches:
  - first-batch
  - second-batch

qa batch two-batches

YAML anchors and aliases

For convenience you can define YAML anchors for common configurations

.base: &base
  - base
  - partial

hdr:
  configs:
    - *base
    - hdr
  inputs:
    - A
    - B
    - C
#=> configs == ["base", "partial", "hdr"]

note

YAML "aliases" and "anchors" are standard YAML feature. Read more here.

Reusable configurations/inputs

Sometimes you want to mix and match reusabe definitions of configs and inputs. YAML anchors let you do it:

.inputs_hdr: &inputs_hdr
  inputs:
    - A
    - B

.lots_of_inputs_hdr: &lots_inputs_hdr
  inputs:
    - A
    - B
    - C
    - D
    - E
    - F

.HDR: &HDR
  configs:
    - *base
    - hdr_base
    - hdr_motion

.HDR-disabled: &HDR-disabled
  configs:
    - *base

hdr:
  <<: *HDR
  <<: *inputs_hdr
no-hdr:
  <<: *HDR-disabled
  <<: *inputs_hdr
# qa --batch-label hdr    batch hdr
# qa --batch-label no-hdr batch no-hdr

# Maybe on nightly runs you want to run lots of inputs
lots-of-hdr-inputs:
  <<: *HDR
  <<: *lots_inputs_hdr
lots-of-no-hdr-inputs:
  <<: *HDR-disabled
  <<: *lots_inputs_hdr
